Main Specifications
1, type style: constant elongation (CRE)
2, load range: 0 ~ 100cN (25, 50, 100cN third gear) or 0 ~ 300cN (50, 150, 300cN third gear);
3, the elongation range: 0 ~ 110mm (when clamping distance of 10mm)
4, the sample holder from: 10 ~ 60mm, precision ∠0.1mm
5, the gripper Area: 4 × 2mm.
6, tensile speed: 0.2 ~ 200mm / min Accuracy ± 2%
7, gripping way: Pneumatic clamping.
8, the sampling frequency: (500-1000) times / Sec.
9, the data output: Display: LCD, strong values, elongation value, tensile curve and the initial modulus print: single value, curve, statistical value of the test data.
10, power supply: 220V / 50Hz, 500W
11, Outline size (length × width × height): Host 400 × 450 × 530mm (not including computers, printers, etc.)
Applicable Standards
GB / T 9997-1988 "Chemical Single fiber breaking force and elongation measurement"
GB / T 14337-1993 "synthetic staple fiber breaking force and elongation test method"
