For the determination of Plastic flat yarn, Plastic woven breaking strength and elongation bag, sling, tons of bags, container bags and other products
The equipment shall be connected to the computer, the user can choose from with a computer or computer manufacturers supporting
【Standards compliant】
GB / T 8050-2007 polypropylene monofilament or film ropes characteristics.
QB / T 2356 a high-density polyethylene monofilament 98
GB / T 8946-1998 Plastic woven bag
GB / T 8947-1998 Composite Plastic woven bag test methods
[Instrument Features]
1, measuring accuracy: the use of high-precision load cell, identified by the State Bureau of Technical Supervision.
2, the display characteristics: a graph dynamic tracking (monitoring) testing process, curvilinear coordinates automatically scale (no need to test intervention), reporting and tracking curve display simultaneously.
3, the operating software: Chinese and English automatic switching.
[Instrument Performance and Main Technical Data]
Press constant elongation (CRE) test measuring principle, the whole process is controlled by the computer instructions, and record every moment of the dynamic changes of the curve and breaking strength, elongation at break (elongation), time and number of times.
1, the test product: monofilament, Plastic woven bag, sling, tons of bags, container bags, etc.
2, range: 10000N / 20000N / 30000N / 50000N (optional)
3. Force measurement accuracy: <± 0.5%
4, chuck distance: 25 ~ 500mm (stepless)
5, tensile speed: 5 ~ 500mm / min (stepless adjustable)
6. Extension Resolution: 0.01mm
7, fixtures: monofilament, fabric, monofilament fabric modular fixture, suspenders jig (optional)
8. Print: breaking strength, tensile strength, elongation, elongation at break time various Form data, curves and statistics
9, Outline size: 750 × 360 × 1680mm
