【 scope of application 】
Used for testing all kinds of cotton, wool, linen, Chemical fiber, glass fiber Fabric, such as non-woven Fabric, breaking strength and elongation at break of geotechnical material, suitable for bag, strap, woven monofilament, waterproofing materials, fishing net wire materials such as breaking strength and elongation of the test. And can customize according to customer request other special fixture!
"Standard"
GB/T 3923, GB/T 3917.2 GB/T 2792 FZ/T 70006-2004 GB/T 13773, GB/T 13772.1 GB/T 13772.2 GB/T 19976-2005 GB/T15788 GB/T13763 JTG E50-2006 GB/T16989 GB/T14800 GB/T1040 L/T235
ASTM D4595 GB/T17640, etc
The instrument features 】
1, precision measuring forces: force transducer with high precision, by the state bureau of technical supervision identification.
2, the controller: the form a complete set of computer control, standard 232 interface connection, strong anti-interference ability, extremely fast, ensure the sampling rate of 1000 times per second or higher; And can handle curve and report at the same time.
3, display features: dynamic tracing display curve (monitoring) testing process, curvilinear coordinates automatically zoom (without testers intervention), report forms and curve tracking shows at the same time.
4, operating software: English a key switch,
The instrument performance and Main Technical Data.
1, the test method: according to the uniform elongation (CRE) test principle, the whole process is controlled by a computer instruction, and record every moment the curve of dynamic change and breaking strength, breaking elongation (elongation), time, number, etc. Can choose according to need strength/elongation, powerful/time, elongation/time curve shows.
2, test methods: Single yarn and Fabric tensile and bursting (optional), stripping, tongue torn, trapezoid tearing, elongation, strength, joint strength, joint efficiency, seam sliding resistance test, etc
4, quantity: 10000 n / 20000 n / 30000 n / 50000 n (optional)
5, force measurement: < plus or minus 1%
6, the clip from 25 to 500 mm (stepless adjustable)
7, stretching speed: 2 ~ 500 mm/min (set arbitrary)
8, regeneration rate: 500 mm/min
9, the effective dynamic range: 600 mm
10, elongation resolution: 0.01 mm
11, gripper clamping width: effective selection according to need
Special fixture (standard configuration: condole belt)
12, print, output various kinds of Form data, curve, print statements
13, electrical source: AC220V plus or minus 10% 50 hz
14, the Outline size: 750 * 360 * 1680 mm
15, heavy quantity: about 300 kg
