Product main parameters:
1. type formula: CRE type
2. Load test range and accuracy:
5000N: Range of measurement Resolution 3000N: Range of measurement Resolution
0 ~ 1250N 0.5N 0 ~ 750N 0.1N
0 ~ 2500N 1N 0 ~ 1500N 0.5N
0 ~ 5000N 3N 0 ~ 3000N 1N
3. Clamping distance: (25 ~ 500) mm stepless
4. Holder: the ripple holder (Φ25 ball bursting rack).
5. Tensile speed: (20 ~ 600) mm / min, stepless <± 2%
6. Test width strip method according to the "Settings" button to convert the linear density.
7. After setting to tensioning. Elongation computing without human factor.
8. Output: LCD data, print output (optional Lenovo tensile curves show data output).
9. The batch has test data (maximum individual and statistical results strong, strength, elongation, etc., minimum, average, CV value) save and query functions.
10. Host Size (L × W × H): 630 × 560 × 1350 mm
11. Power: 220V, 50Hz, 1kW
