Floor arm Host, large screen Chinese LCD, with data storage, retrieval, statistics, printing, the printer can be independently configured EPSON300K (plus 2,000 yuan), print test data report.
You can also configure computers, color monitors and inkjet printers, output graphs and reports (plus 5000).
To achieve a two-way interactive control console panel key operation (SCM) and computer keyboard can be arbitrarily choose.
PC with WINDOWS XP operating system.
User interface text in Chinese and English bilingual selection.
C, test functions:
(1) Tensile breaking test (program and fixture)
Maximum strength Range of measurement are: 50KG, 100KG, 300KG (to ensure accuracy, Range of measurement can be sub-file). Range of measurement range of 1-120% scale value: 0.1N, Accuracy: 1%, 0.1% FS, load resolution: 1/50000
Gripping distance: 20-500MM stepless, digital set, automatic positioning.
Tensile speed: 10-1000MM / MIN, division value: 1MM / MIN, accuracy: 2%
Reply speed: 10-1000MM / MIN, division value: 1MM / MIN, accuracy: 2%
Effective stroke: 900MM, elongation Resolution: 0.1 / 0.01MM
(2) tear (single tongue and double tongue, trapezoidal) test (program and fixture) 3000 yuan
(3) peel test (program and fixture) 3000 yuan (4) yarn, rope, wire strength test (program and fixture) 3000 yuan
(5) constant elongation strength
(6) given the strong elongation
D, a variety of national standard, Unit switch select:
GB, ISO, AATCC, BS.DIN, JIS, etc., N, KN, KG, LB and so on.
E, the above test functions are manually clamped.
F, Product Dimensions:
